Wide-Band Tapper 550-4000MHz 952XXXX7
|
Electrical Specifications |
||||||||||||||||||||||
|
Type No. |
4.3-10 Female |
95205897 |
95206897 |
95207897 |
95208897 |
95209897 |
95210897 |
|||||||||||||||
|
Output Power Split Ratio(dB) |
2:1/3 |
3:1/4.8 |
4:1/6.0 |
6:1/8.0 |
7:1/8.5 |
10:1/10 |
||||||||||||||||
|
Tap Loss(dB) |
J3/J2 →J1 |
-1.8 / -4.8 |
-1.3 / -6.1 |
-1.0 / -7.0 |
-0.7 / -8.6 |
-0.6 / -9.0 |
-0.4 / -10.4 |
|||||||||||||||
|
Coupling Tolerance |
±0.8 |
±0.8 |
±0.8 |
±0.8 |
±1.0 |
±1.0 |
||||||||||||||||
|
Return Loss(dB) |
550-4000MHz |
≥18 |
≥19 |
≥19 |
≥20 |
≥20 |
≥20 |
|||||||||||||||
|
Type No. |
4.3-10 Female |
95213897 |
95215897 |
95220897 |
95230897 |
|||||||||||||||||
|
OutputPower Split Ratio(dB) |
20:1/13 |
30:1/15 |
100:1/20 |
1000:1/30 |
||||||||||||||||||
|
Tap Loss (dB) |
J3/J2 →J1 |
-0.2 / -13.2 |
-0.1 / -15.1 |
-0.1 / -20.1 |
-0.1 / -30.1 |
|||||||||||||||||
|
Coupling Tolerance |
±1.0 |
±1.3 |
±1.3 |
±1.3 |
||||||||||||||||||
|
Return Loss(dB) |
550-4000MHz |
≥21 |
≥21 |
≥21 |
≥21 |
|||||||||||||||||
|
Frequency Range (MHz) |
550-4000 |
|||||||||||||||||||||
|
PIM3 (@2x43 dBm Carrier) (dBc) |
< -160 |
|||||||||||||||||||||
|
Input Power (W) |
< 500 |
|||||||||||||||||||||
|
Peak Power (W) |
< 1500 |
|||||||||||||||||||||
|
Impedance (Ω) |
50 |
|||||||||||||||||||||
| Mechanical Specifications | |
| Dimensions,HxWxD(excluding connectors and mounting bracket)(mm) | 65.5x25x25 |
| Weight (including connectors and mounting bracket) (kg) | 0.26(4.3-10 Female) |
| Packing Size(mm) | 135x70x55(30Pcs/box) |
| Color | Light Gray(Customizable) |
| Mounting | Wall Mounting |
Main Functions
Precision Signal Sampling: Provides directional coupling from main path (J1→J2) to tap port (J3) with selectable coupling ratios (-2dB to -1000dB), enabling non-intrusive RF signal monitoring.
Minimal Main Path Loss: Maintains ultra-low insertion loss (as low as 0.1dB) on the primary transmission line (J1→J2) while extracting tapped signals, preserving system efficiency.
Broadband Signal Integrity: Operates across 550–4000MHz (covering 5G/LTE/Wi-Fi) with stable 50Ω impedance and high return loss (≥18–21dB), ensuring accurate measurements.
Typical Application Scenarios
Cellular Network Monitoring: Deployed at base stations to sample transmit/receive signals for VSWR alarms, drive-test equipment, or interference analysis without disrupting main RF paths.
DAS Performance Verification: Used in distributed antenna systems to monitor signal levels across multiple zones in stadiums or buildings (IP65-rated for harsh environments).
Field Test & Optimization: Essential for RF engineers verifying power distribution, identifying reflections, or troubleshooting in live networks (-40°C to +65°C operational range).
Technical Features
Versatile Coupling Options: Offers 12 standardized coupling ratios (-2dB to -1000dB) with tight tolerance (±0.8–±1.3dB), catering to diverse monitoring needs.
High-Fidelity Performance: Features ultra-low PIM (<-160dBc) and low insertion loss (e.g., -0.1dB for -30dB coupling), critical for sensitive measurements.
Robust Compact Design: Supports high power (500W continuous/1500W peak) in a miniature square tube (65.5x25x25mm, 0.26kg) with IP65 protection and wall mounting. Efficient packaging (30 units/box) reduces deployment costs.
|
Environmental Specifications |
|
|
Operational Temperature (°C) |
-40 to +65 |
|
Operational Humidity (%) |
≤95 |
|
Ingress Protection Class |
IP65(Indoor and Outdoor) |
|
Accessories(order separately) |
|
|
Type No. |
Description |
|
50403.0200955 |
Bracket |
